Out Here In The Field : Journeys

It’s been a while after my post about my Pentax K100D. I have updated the post to include some infos about using AF to help you manually focus the SMC-M 50mm F1.4, do check it

The latest “toy” that came to my possession is the AF-360FGZ Flash unit, which is a quite versatile unit. It has the GN number of 36, and support P-TTL, TTL, Auto and Manual mode. It support High Sync function, so you can use it as fill-in flash. It comes with a built in diffuser, and a white card that can be used to direct some light forward when the flash is set to bounce. This unit can also be triggered wirelessly (in dumb mode) using the built-in flash unit of K100D. Sadly this unit can’t swivel, so it might be useless when using the camera vertically. Some of the folk at pentax-indonesia mailinig list claimed that this flash unit is too expensive, and not really worth the money. But hey, since they sell it on a bargain, I think it’s a good buy

Anyway I’m not gonna write about using the AF-360FGZ with my digital lens, instead I’m gonna tell you my experience on using the unit with my SMC-M 50mm F1.4. I’m still pretty much novice in this kind of thing, so please bear with me if some of thing that I wrote is not right.

My novice experience in using the the M 50mm lens with the built-in flash unit on my K100D are mostly painful. Since I have limited power in controlling the power of the built-in flash, I compensate this by adjusting the aperture. This is fine when I need to use small aperture. But when the shot require large aperture (2-2.8) tight DOF, the built-in flash became useless, since at the lowest power setting (-3), it still gaves you too much light.

With the AF-360FGZ, I have a whole lot more control over the amount of light it produces. Since the 50mm manual doesn’t tell the body what aperture its currently set to, P-TTL/TTL is out of question. Also you can not use High Sync function, so you need other way to control the light produced by the flash.

So I switched the flash to use “Auto” by pressing the “MODE” button until “A” is displayed on the LCD. In Auto mode, you can setup 3 parameters. The first one is ISO value. When using the flash as fill in, you will want to set this as low as possible. Press the “S” button until the ISO value on the LCD flashes. Enter the desired value by scrolling the wheel around the “S” button. The second is the aperture value. Set is according to the F value that you use on the lens. Again, press the “S” button until the F value on the LCD flashes and set the desired value by scrolling the wheel around the “S” button. If the flash still produce to much light, you can put lower value in this parameter. Additionally, you can set the zoom level by pressing the “Zoom” button, or leave it on auto (“A-Zoom”).

This one is cropped out of picture taken using the 50mm on large aperture (2.0 if I’m not mistaken), while using the AF-360FGZ for fill-in. The light is further soften by bouncing the flash upward, and using the built-in diffuser

The use of flash is still evident as you can see some light reflection on the lens at the middle. As you can see from the picture above, the desired DOF can be acquired by using large aperture, and the AF-360FGZ provided additional lighting needed for the shot. This method is far from perfect, and if you have any input and advice, do share it here

The SMC P-M 50mm F1.4 is my first prime lens for my K100D. I bought it from a second hand camera shop at Pasar Baru for quite a cheap price. It wasn’t in mint condition, and didn’t come with front and back lens cap. But still very usable and produces quite sharp pictures.

Anyway, unlike the “A” lens, the “M” doesn’t come with “Auto” setting for aperture. On an “A” (and above, except the DA and DA*) lens, Auto setting lets you set the aperture value from the camera body, instead of the aperture ring. This means, with an “M” lens, the only way to set the aperture value, is through the aperture ring on the lens.

On a plus side, since K100D Shake Reduction function is onboard of the camera body, this means any lens, including my old “M” lens will have shake reduction feature.

To use my SMC P-M 50mm F1.4 on K100D, I have to do several steps:

1. Setup SR function
Unlike newer lenses, the SMC P-M 50mm F1.4 doesn’t provide focus length and aperture info needed for the SR function to work, so you have to manually input them. When I mount the lens to my K100D and turn my camera on, it automatically ask you to input the focus length infos. You can change the value by entering the “Rec. Mode” menu via the “MENU” button, and change the “Shake Reduction” value.

2. Allow the use of aperture ring
Go to the “Custom Setting” menu via “MENU” button, change the “Using aperture ring” value to “2 Permitted”. This setting will allow you to set aperture by using the aperture ring on the lens.

3. Change the AE-L button function
Go to the “Custom Setting” menu via “MENU” button, change the “AE-L bttn on M expsr” value to “2 Tv Shift”. This setting will let the camera to shift shutter speed when the “AE-L” button is pressed on manual mode.

4. Switch to Manual Mode
To put the camera into Manual Mode, turn the dial to point to “M”. Manual Mode will let you set the aperture value via the aperture ring on the lens. You can shoot in “Av” mode, but it will only work with the aperture open wide.

5. Switch to manual focus
Actually, you can shoot in “AF” but only if the focus is confirmed. Switching to “MF” will let you shoot anytime.

6. Select the correct ISO
On Manual Mode, Auto-ISO doesn’t work, so you need to setup the ISO value manually.

When you have followed above steps, you are ready to shoot with your SMC P-M lens, here are the steps:

1. Set aperture value via the aperture ring
2. Frame your shot
3. Focus with the lens focus ring
4. Press the shutter halfway to confirm focus (optional)
5. Press the AE-L button to get shutter speed
6. Shoot

As a side note, DOF on a F1.4 lens is pretty tight, the lens is best used when stopped down. You don’t have to press the AE-L button every time you shoot, and you can always manually set the shutter speed, if you want.

Here’s a sample shot from the M 50mm:

This one is taken with the M 50mm and a Metz 32-Z1 flash unit.

UPDATE@01/05/2008

dubesor pointed me to a discussion on dpreview on similar topic by Sean Nelson. One of the step that I stated was to switch the focusing method from AF to MF, since on AF, you can only shoot when the focus is confirmed by the camera. From my experience, getting focus confirmation on this lens is kinda hard, and even when the focus is confirmed, you usually are required to make small adjustment, hence throwing the focus confirmation off, and leave you unable to shoot.

But if you’re confident enough with the focus confirmation, shooting in AF can help you focus in some way. First you manually focus as best as you can, press “AE-L” to meter, and then fully press the shutter. It won’t rightly shoot, since you don’t have the focus confirmation yet. Then you adjust the focus by moving the camera slowly toward or away from the object. As soon as the camera detect the focus confirmation, it’ll automatically take the shot.

There are some major drawbacks with this method. One, there will be camera shake, since the shot is taken while you move the camera. Luckily, with K100D, you’ll have SR function virtually on all of your lens. The second, is that you will not be able to compose your shot. While using the M lens, instead of 11 focus point, You’ll only have a single focus point, which is right in the middle. Since the focus confirmation only works on the focus point, you need to put the object of the photo right in the middle of the frame of your shot. So recomposing your shot is required, if you want to use the focus confirmation function, and put the focus object other than in the middle of the frame of your shot. With the first method (using MF instead of AF), when the focus is confirmed by the body, you can lock the focus by keep half-pressing the shutter button, and proceed to recompose the frame. Or if you don’t need focus confirmation, you can immediately start focusing after composing the shot. But when shooting in AF, you need to fully press the shutter, eliminating focus lock function, and the resulting the shot taken as soon as the focus is confirmed.
